Binocular head or trinocular head Siedentopf type, 30º inclined (Light split 100:0/20:80). Widefield high eyepoint N-WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Crosshair reticle on one eyepiece. Intermediate tube with rotatable analyzer 360º and Bertrand lens. Empty insertion plate. Reversed quadruple revolving nosepiece, single positions centrable. CCIS EC Plan Strain-free objectives EC PL 4X, 10X, 40X S, 60X S. Coaxial coarse and fine focusing with tension adjustment. 360º circular rotating stage. Achromat swing-out condenser N.A. 0.90/0.13 (strain-free) with iris diaphragm. Rotatable polarizer, fixed on condenser carrier. Koehler illumination quartz halogen 6V/30W with intensity control. Universal supply 100-240 V (CE). 45mm blue filter, power cord, Allen hexagonal key, vinyl dust cover. 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Monocular or binocular head 45º inclined and 360º rotating. Widefield WF 10X/18 mm eyepieces with cross reticle. Reversed quadruple revolving nosepiece with achromatic objectives EA 4X, 10X and 40X S. Coaxial coarse and fine focusing adjustment. Working table rotating from 0360° with graduation to 1°. Focusable 1.25 N.A. Abbe condenser. Iris diaphragm with filter holder. Includes a swing in/out analyser and polarizer. LED illumination 0,5 W with intensity control. Dust cover included. Supply 220-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
