Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. For digital model only: binocular head, Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2 chip 2048 x 1536 pixels with USB 2.0 output. Widefield high eyepoint N-WF10X/20 mm eyepieces with dioptric adjustment in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan Achromatic objectives (Colour Corrected Infinity System) EC Plan 4X, EC Plan 10X, EC Plan 40X S and EC Plan 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Low position coaxial mechanical stage with controls at right side. Focusable 1.25 N.A. Abbe condenser with iris diaphragm and slot. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Digital model includes calibration slide and Motic Images Plus 3.0 Software for PC and Mac. Koehler LED illumination 3W with intensity control. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. For digital model only: binocular head, Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2 chip 2048 x 1536 pixels with USB 2.0 output. Widefield N-WF10X/20 mm eyepieces. Reversed quadruple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) EC Plan 4X, EC Plan 10X, EC Plan 40X Spring and EC Plan 100X Spring-Oil. Coaxial coarse and fine focusing with tension adjustment. Low position coaxial mechanical stage with controls at right side. Focusable 1.25 N.A. Abbe condenser with iris diaphragm and slot. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Digital model includes calibration slide and Motic Images Plus 3.0 Software for PC and Mac. LED illumination 3W with intensity control. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular, binocular or trinocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepieces. Quadruple revolving nosepiece with achromatic Semi-Plan SP objectives 4X, 10X, 40X S and 100X S-Oil. Coaxial coarse and fine focusing system. Low position coaxial mechanical stage. Focusable 1.25 N.A. Abbe condenser. Iris diaphragm with filter holder. LED illumination 3W with intensity control. Dust cover and immersion oil included. Main supply 220-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular, binocular or trinocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepiece. Quadruple nosepiece with achromatic EA objectives 4X, 10X and 40X S. Separate (1802 model) or coaxial (2820 & 2823 models) coarse and fine focusing system. Built in low position coaxial mechanical stage. Focusable 1.25 N.A. Abbe condenser. Iris diaphragm with filter holder. LED 20 mA, 3.5 V, 70 mW illumination with intensity control. Dust cover included. Main supply 100-240 V (CE), batteries and charger included. 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular head, inclined at 45 degrees and rotating 360º. Widefield WF10X/18mm eyepiece with built-in pointer. Achromatic DIN objectives 4X, 10X, 40X S Coarse and fine focusing adjustment. 0.65NA fixed condenser. Iris diaphragm with filter holder. LED 20 mA, 3.5 V, 70 mW illumination, with intensity control. Cover included. Main supply 100-240 V (CE), batteries and charger included. Warranty 5 years on optical and mechanical components. Delivery time 3-4 weeks
