Monocular or binocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepiece. Quadruple nosepiece with achromatic DIN objectives 4X, 10X, 40X S and 100X S-Oil . Coarse and fine focusing adjustment. Focusable 1.25 NA Abbe condenser. Built in low position coaxial mechanical stage Iris diaphragm with filter holder. LED illumination with intensity control. Main supply 110-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint N-WF10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Side facing quadruple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) PL4X and CCIS Plan Achromatic Phase objectives PL Ph10X (Ph1) and LWD PL Ph20X (Ph 1). ELWD condenser N.A. 0.30. Phase slider Ph1, BF, Ph2Phase centering telescope. Plain stage with metal and glass stage inserts. Ø 45 mm blue, green interference and neutral density filters with filter slider, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Quartz halogen illumination 6V/30W with intensity control and sleeping mode. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Moticam BTW. Adaptative digital camera with an attachable C-mount. Tablet bracket included for tablets from 7″ to 10″ (Tablet not included. Users can use their own tablet and connect through Wi-Fi). Sensor type: CMOS. Sensor size: 1/2,5″. Live resolution: 1280 x 720 pixels (16:9), 1280 x 960 & 800 x 600 (4:3). Image capture resolution: 5.0MP. Output: USB or Wi-Fi. Motic Images Plus 3.0 for Windows, OSX and Linux. Motic 4-dot calibration slide. Power Supply 100V-240V (CE). 2 years warranty. Delivery time 2 weeks
FullHD camera for microscopy with HDMI (1080p) output, USB output and 1920×108 pixels resolution in real time. Images can be captured directly onto an SD card at 8.0 Mp resolution. Screen: LCD 11,6” Full HD (available only for MOTICAM 1080 BMH). Software On Board (allows you to control the camera parameters by connecting a mouse to the USB). Eyepiece couplers for connection to the most common microscope eyepieces of any brand (available only for MOTICAM 1080). Focusable macro lens. Calibration slide included. Motic Images Plus 3.0 Software for image capture and edition with Windows and MAC (multilanguages software, English included). 2 years warranty. Delivery time 2 weeks
Local / remote commuter with intensity control. Intensity remote control (2 m). LED reading of colour temperature. Universal supply 100-240 V (CE). 21 V/150 W halogen bulb included. 2 years warranty. Delivery time 2 weeks
Two models are available: BA310 MET (Reflected light system) and BA310MET-T (Reflected&Transmitted light system). Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) LM PL 5X, 10X, 20X, 50X. Coaxial coarse and fine focusing system. Mechanical stage 180 x 140 mm, hard coated with built-in low position coaxial stage control. Focusable 1.25 N.A. Abbe condenser with iris diaphragm (model BA310 MET-T). Blue filter Ø45 mm, dust cover, hexagonal Allen key. Epi-illuminator 12V/50W quartz halogen with integrated field and aperture diaphragms and external lamp house. Transmitted Koehler illumination quartz halogen with 6V/30W with intensity control (model BA310 MET-T). Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed sextuple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) EC-H. Plan 4X, 10X, 40X S and 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Rackless low position coaxial mechanical stage with controls at right side and sample holder, ceramic insert. Achromat swing-out condenser N.A. 0.90 with iris diaphragm. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Koehler halogen illumination 12V/50W with external lamp house and intensity control. Auto-OFF and Light Memory function. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
