Monocular or binocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepiece. Quadruple nosepiece with achromatic DIN objectives 4X, 10X, 40X S and 100X S-Oil . Coarse and fine focusing adjustment. Focusable 1.25 NA Abbe condenser. Built in low position coaxial mechanical stage Iris diaphragm with filter holder. LED illumination with intensity control. Main supply 110-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint N-WF10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Side facing quadruple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) PL4X and CCIS Plan Achromatic Phase objectives PL Ph10X (Ph1) and LWD PL Ph20X (Ph 1). ELWD condenser N.A. 0.30. Phase slider Ph1, BF, Ph2Phase centering telescope. Plain stage with metal and glass stage inserts. Ø 45 mm blue, green interference and neutral density filters with filter slider, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Quartz halogen illumination 6V/30W with intensity control and sleeping mode. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Two models are available: BA310 MET (Reflected light system) and BA310MET-T (Reflected&Transmitted light system). Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) LM PL 5X, 10X, 20X, 50X. Coaxial coarse and fine focusing system. Mechanical stage 180 x 140 mm, hard coated with built-in low position coaxial stage control. Focusable 1.25 N.A. Abbe condenser with iris diaphragm (model BA310 MET-T). Blue filter Ø45 mm, dust cover, hexagonal Allen key. Epi-illuminator 12V/50W quartz halogen with integrated field and aperture diaphragms and external lamp house. Transmitted Koehler illumination quartz halogen with 6V/30W with intensity control (model BA310 MET-T). Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed sextuple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) EC-H. Plan 4X, 10X, 40X S and 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Rackless low position coaxial mechanical stage with controls at right side and sample holder, ceramic insert. Achromat swing-out condenser N.A. 0.90 with iris diaphragm. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Koehler halogen illumination 12V/50W with external lamp house and intensity control. Auto-OFF and Light Memory function. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. For digital model only: binocular head, Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2” chip 2048 x 1536 pixels with USB 2.0 output. Widefield high eyepoint N-WF10X/20 mm eyepieces with dioptric adjustment in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan Achromatic objectives (Colour Corrected Infinity System) EC Plan 4X, EC Plan 10X, EC Plan 40X S and EC Plan 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Low position coaxial mechanical stage with controls at right side. Focusable 1.25 N.A. Abbe condenser with iris diaphragm and slot. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Digital model includes calibration slide and Motic Images Plus 3.0 Software for PC and Mac. Koehler LED illumination 3W with intensity control. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. For digital model only: binocular head, Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2” chip 2048 x 1536 pixels with USB 2.0 output. Widefield N-WF10X/20 mm eyepieces. Reversed quadruple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) EC Plan 4X, EC Plan 10X, EC Plan 40X Spring and EC Plan 100X Spring-Oil. Coaxial coarse and fine focusing with tension adjustment. Low position coaxial mechanical stage with controls at right side. Focusable 1.25 N.A. Abbe condenser with iris diaphragm and slot. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Digital model includes calibration slide and Motic Images Plus 3.0 Software for PC and Mac. LED illumination 3W with intensity control. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular, binocular or trinocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepieces. Quadruple revolving nosepiece with achromatic Semi-Plan SP objectives 4X, 10X, 40X S and 100X S-Oil. Coaxial coarse and fine focusing system. Low position coaxial mechanical stage. Focusable 1.25 N.A. Abbe condenser. Iris diaphragm with filter holder. LED illumination 3W with intensity control. Dust cover and immersion oil included. Main supply 220-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular, binocular or trinocular head (according to model), 45º inclined and 360º rotating. Widefield WF10X/18 mm eyepiece. Quadruple nosepiece with achromatic EA objectives 4X, 10X and 40X S. Separate (1802 model) or coaxial (2820 & 2823 models) coarse and fine focusing system. Built in low position coaxial mechanical stage. Focusable 1.25 N.A. Abbe condenser. Iris diaphragm with filter holder. LED 20 mA, 3.5 V, 70 mW illumination with intensity control. Dust cover included. Main supply 100-240 V (CE), batteries and charger included. 5 years warranty on optical and mechanical components. Delivery time 3-4 weeks
Monocular head, inclined at 45 degrees and rotating 360º. Widefield WF10X/18mm eyepiece with built-in pointer. Achromatic DIN objectives 4X, 10X, 40X S Coarse and fine focusing adjustment. 0.65NA fixed condenser. Iris diaphragm with filter holder. LED 20 mA, 3.5 V, 70 mW illumination, with intensity control. Cover included. Main supply 100-240 V (CE), batteries and charger included. Warranty 5 years on optical and mechanical components. Delivery time 3-4 weeks
