Made of amber borosilicate glass 3.3. Fully autoclavable at 134 ºC. GL 45 thread, according to ISO 4796. With blue screw cap and pouring ring in polypropylene
Moticam BTW. Adaptative digital camera with an attachable C-mount. Tablet bracket included for tablets from 7″ to 10″ (Tablet not included. Users can use their own tablet and connect through Wi-Fi). Sensor type: CMOS. Sensor size: 1/2,5″. Live resolution: 1280 x 720 pixels (16:9), 1280 x 960 & 800 x 600 (4:3). Image capture resolution: 5.0MP. Output: USB or Wi-Fi. Motic Images Plus 3.0 for Windows, OSX and Linux. Motic 4-dot calibration slide. Power Supply 100V-240V (CE). 2 years warranty. Delivery time 2 weeks
FullHD camera for microscopy with HDMI (1080p) output, USB output and 1920×108 pixels resolution in real time. Images can be captured directly onto an SD card at 8.0 Mp resolution. Screen: LCD 11,6” Full HD (available only for MOTICAM 1080 BMH). Software On Board (allows you to control the camera parameters by connecting a mouse to the USB). Eyepiece couplers for connection to the most common microscope eyepieces of any brand (available only for MOTICAM 1080). Focusable macro lens. Calibration slide included. Motic Images Plus 3.0 Software for image capture and edition with Windows and MAC (multilanguages software, English included). 2 years warranty. Delivery time 2 weeks
Local / remote commuter with intensity control. Intensity remote control (2 m). LED reading of colour temperature. Universal supply 100-240 V (CE). 21 V/150 W halogen bulb included. 2 years warranty. Delivery time 2 weeks
Greenough zoom optical system. Binocular head 45º inclined with built-in digital camera CMOS 1/2” 5mp (2592 x 1944) with USB 2.0 output. Widefield WF10X/20 mm eyepieces. Zoom ratio 4:1 and magnification range 1X-4X. 80 mm working distance. FBGG: pole type stand with large working base. Coarse focusing system with tension adjustment. Incident and transmitted halogen 12V/10W illumination with intensity control. Dust cover and calibration slide included Motic Images Plus 3.0 Software for PC and Mac. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular head 45º inclined. Widefield WF10X/20mm eyepieces. Turret-type magnification changer with 2X and 4X objectives. Incident and transmitted (according to model) tungsten 12V/10W or LED 20 mA, 3.5V, 70 mW illumination. Dust cover included. Supply 220-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Two models are available: BA310 MET (Reflected light system) and BA310MET-T (Reflected&Transmitted light system). Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) LM PL 5X, 10X, 20X, 50X. Coaxial coarse and fine focusing system. Mechanical stage 180 x 140 mm, hard coated with built-in low position coaxial stage control. Focusable 1.25 N.A. Abbe condenser with iris diaphragm (model BA310 MET-T). Blue filter Ø45 mm, dust cover, hexagonal Allen key. Epi-illuminator 12V/50W quartz halogen with integrated field and aperture diaphragms and external lamp house. Transmitted Koehler illumination quartz halogen with 6V/30W with intensity control (model BA310 MET-T). Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular head or trinocular head Siedentopf type, 30º inclined (Light split 100:0/20:80). Widefield high eyepoint N-WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Crosshair reticle on one eyepiece. Intermediate tube with rotatable analyzer 360º and Bertrand lens. Empty insertion plate. Reversed quadruple revolving nosepiece, single positions centrable. CCIS EC Plan Strain-free objectives EC PL 4X, 10X, 40X S, 60X S. Coaxial coarse and fine focusing with tension adjustment. 360º circular rotating stage. Achromat swing-out condenser N.A. 0.90/0.13 (strain-free) with iris diaphragm. Rotatable polarizer, fixed on condenser carrier. Koehler illumination quartz halogen 6V/30W with intensity control. Universal supply 100-240 V (CE). 45mm blue filter, power cord, Allen hexagonal key, vinyl dust cover. 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. Widefield high eyepoint WFPL10X/20 mm eyepieces with dioptric adjustment and protectors in both eyepieces. Reversed sextuple nosepiece with CCIS Plan achromatic objectives (Colour Corrected Infinity System) EC-H. Plan 4X, 10X, 40X S and 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Rackless low position coaxial mechanical stage with controls at right side and sample holder, ceramic insert. Achromat swing-out condenser N.A. 0.90 with iris diaphragm. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Koehler halogen illumination 12V/50W with external lamp house and intensity control. Auto-OFF and Light Memory function. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
Binocular or trinocular head (according to model) Siedentopf type, 30º inclined and 360º rotating. For digital model only: binocular head, Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2” chip 2048 x 1536 pixels with USB 2.0 output. Widefield high eyepoint N-WF10X/20 mm eyepieces with dioptric adjustment in both eyepieces. Reversed quintuple revolving nosepiece with CCIS Plan Achromatic objectives (Colour Corrected Infinity System) EC Plan 4X, EC Plan 10X, EC Plan 40X S and EC Plan 100X S-Oil. Coaxial coarse and fine focusing with tension adjustment. Low position coaxial mechanical stage with controls at right side. Focusable 1.25 N.A. Abbe condenser with iris diaphragm and slot. Blue filter Ø45 mm, dust cover, hexagonal Allen key and immersion oil 5 ml bottle included. Digital model includes calibration slide and Motic Images Plus 3.0 Software for PC and Mac. Koehler LED illumination 3W with intensity control. Universal supply 100-240 V (CE). 5 years warranty on optical and mechanical components. Delivery time 2-3 weeks
